Wall-Mounted Basins

What Is a Wall-Mounted Basin?

A wall-mounted basin is fixed directly to the wall rather than resting on a pedestal or sitting on a vanity unit counter. Because there is no pedestal column below, the floor beneath the basin is completely clear — making the room feel more open and making floor cleaning much easier. The waste trap and supply pipes either run inside the wall behind a concealed bottle trap, or sit exposed below the basin with a chrome, matt black or brushed gold trap and flexi-pipes to match the tap finish. Wall-mounted basins come in compact widths from around 360 mm for cloakrooms and en-suites, up to standard widths of 500–600 mm for main bathrooms. Most models offer one or three tap holes.

Installation and What to Check

Wall-mounted basins must fix into a load-bearing wall or a timber-framed support noggin built into a stud wall — the basin and user's weight transfers entirely through the wall fixings. If you are building a new stud wall or partition, always install the support structure before tiling. Waste traps and bottle traps are available in chrome, matt black and brushed gold to match tap finishes. For compact wall-hung options sized for cloakrooms, browse Cloakroom Basins. For a vessel-style basin on a counter, see Counter-Top Basins. For a traditional pedestal installation, visit Full-Pedestal Basins. Return to Basins for the complete range.
