Bathroom 2 Dial 2 Way Square Concealed Thermostatic Valve with Shower Handset

Thermostatic Valve Features

• Left dial: Temperature control
• Middle Dial: Controls water flow
• High quality design
• Chrome finish
• Thermostatically controlled
• Manufactured from highly durable brass
• Hot supply temperature: 55-65ºC
• Cold supply temperature: 5-25ºC
• Maximum static pressure: 10 bar
• Built in non return valves to prevent back flow and filters to protect the thermostatic mechanism
• UK standard size fitting

Water Flow Rates

Flow Rates:

• 0.1 Bar-6.5
• 0.5 Bar-9.7
• 1 Bar-14
• 1.5 Bar-17.5
• 2 Bar-20.5
• 3 Bar-27

Suitable for the following water systems

• Combi-boilers
• Gravity fed systems
• MegaFlow systems
• Pumped systems
• Un-vented systems
• Pressurised cylinder systems
• Flow pressure, hot & cold: 0.5-5 bar

Package Contents

• 1 X Thermostatic valve
• 1 X Shower handset
• 1 X Bracket
• 1 X Shower hose
• 1 X Installation Guide
