Description
This is an innovative thermostatic shower concealed mixer valve with 2 outlets. The one outlets is a state-of-the-art styling with modern technology to give you a high-class shower valve for your bathroom. This shower valve offers the essential flexibility to your wet room- the two-button valve enables 2 shower accessories to be managed independently or simultaneously. The layout of the valve with push-button control offers a sleek and stylish design appearance. The pushbuttons function as an on and off switch for the outlet, providing you with a rejuvenating shower with the simplest touch of a button. Thermostatic dial control maintains a constant temperature in all conditions. This can be Installed only Horizontally.
Key Features
- This is an innovative thermostatic shower concealed mixer valve with 2 outlets
- State-of-the-art styling with modern technology to give you a high-class shower valve for your bathroom
- Shower valve offers the essential flexibility to your wet room
- The layout of the valve with push-button control offers a sleek and stylish design appearance
- The pushbuttons function as an on and off switch for the outlet, providing you with a rejuvenating shower with the simplest touch of a button
Specification
- Two Buttons - controls water to 2 outlet diverter
- Bottom Dial: Temperature control
- Inlet Connection Size: 2x 3/4"
- Outlet Connection Size: 2x 1/2"
- Modern High-Quality Design
- Polished Chrome Finish
- Thermostatically Controlled
- Constructed from highly durable brass
- Concealed shower valve for a minimalist feel
- Operating range 20 - 50 deg C with 38 deg C safety button
- Built-in non-return valves to prevent backflow and filters to protect the thermostatic mechanism
- Chosen temperature maintained to within +/-1ºC
- Pre-set maximum temperature
- Automatic shut off in event of water cold supply failure
- UK standard size fitting
Technical Information
Suitable for the following water systems:
- Combination boiler systems
- Gravity-fed systems (only with a pump)
- MegaFlo systems
- Pumped hot water systems
- Unvented hot water systems
- Standard pressurised hot water cylinder type systems
- Minimum pressure: 1.0 bar
- Maximum pressure: 6 bar
Package Contents
- 1x Concealed Thermostatic Shower Mixer Valve
- 1x Shower Handset
- 1x Hose
